Unidirectional Carbon fibe prepreg T700SC-12000-50C and epoxy resin system high Modulus 233GPa

Name: Unidirectional Carbon fibe prepreg T700SC1200050C and epoxy resin system high Modulus 233GPa
Brand: SKYWELL
Price: 4 USD

Wholesale Unidirectional Carbon fibe prepreg T700SC-12000-50C and epoxy resin system high Modulus 233GPa from china suppliers

Brand Name : SKYWELL

Model Number : T700SC-12000-50C

Certification : SGS

Place of Origin : Japan

MOQ : 10 m2

Price : USD4-6 per m2

Payment Terms : L/C, , T/T, Western Union,Paypal

Supply Ability : 100000 m2 per month

Delivery Time : 2-3 days

Packaging Details : Box size 110*35*35CM

Carbon fiber : T700SC-12000-50C

FAW (fiber content [g/m2 : 75

Resin Content [g/m2 : 37

Twist : No Twist

Resin system : Epoxy

Curing temperature : 125 Celsius

Tensile Strength Mpa [kgf/mm2] : 5410

Tensile modulus [GPa[10³ kgf/mm2] : 233

Elongation : 2.3%

Density [10³kg/m³] : 2

YIELD : 809

Process : Filament Winding - Pultrusion - Prepreg

Typical Applications : Motorsport, Sport & leisure, Industrial

Contact Now

Unidirectional Carbon fibe prepreg T700SC-12000-50C and epoxy resin system high Modulus 233GPa

We provide carbon fiber prepregs, including UD prepregs (in which carbon fibers are unidirectionally stretched and impregnated with resin) and cross prepregs (that is, carbon fiber woven cloth impregnated with resin).
Ultra-high modulus PAN carbon fiber is widely used as a material for manufacturing automobiles and sports products. Other applications include construction/civil engineering and aerospace industry.

Unidirectional Carbon fibe prepreg T700SC-12000-50C and epoxy resin system high Modulus 233GPa
It can be impregnated with epoxy resin according to customer requirements, and it is developed assuming use in different high temperature ranges. Using this prepreg can expand the application range of the product.

Specification:

Resin system	Epoxy
Tensile Strength	710.7 KSI
Tensile Modulus	33.4 MSI
Elongation	2.3%
Denisty	0.065 lb/in³
Filament diameter	0.28 mil
Resin	Epoxy
Size content	1%
Precursor	Pan
K	12k
Twisted	Never
Tow Size	Small tow
Cross sectional area	68.2[in2.10³]
Resistivity (23 Celsius)	630 x10^-6 [Ω.in]

Application:

Sport products ,such as ice hockey stick, golf shaft,Ski poles,bicycle and so on .
Transportation :Auto parts,boats and ships,Aerospace,Drone etc.
New energy: wind power,Solar energy etc.
Industrial manufacturing :Robotic arm, Automated modification etc

Unidirectional Carbon fibe prepreg T700SC-12000-50C and epoxy resin system high Modulus 233GPa
